Fluteless taps M14 x 1,5 / 6HX / ~DIN 374 / HSS-E-PM / TiN
-
Connection code machine side: straight shank -
Internal cooling: without -
Standard: ~DIN 374 -
Surface: TiN -
Cutting direction: right-hand -
Type: N -
Tool material: HSS-E-PM -
Form: C -
Tolerance field: 6HX -
Hole type: through-, blind hole
SKU
1258 14.007
EAN
4031093702324
To see prices, please log in.
New customers can create a user account HERE or add the desired products to the shopping cart and then send a request for quotation.
Item is not available
Note
Product added to cart.
Loading...
Fluteless taps M14 x 1,5 / 6HX / ~DIN 374 / HSS-E-PM / TiN
Fluteless machine taps for ISO metric fine threads M14 x 1,5 / 6HX / 1.5xD / ~DIN 374 / DIN 2174 / HSS-E-PM / TiN / Type: N / Form: C / through-, blind hole / Cutting direction: right-hand
ISO code
| P | Steel, high-alloyed steel |
|---|---|
| M | Stainless steel |
| K | Grey cast iron, spher, graphite/mall. cast iron |
| N | Aluminium and other non-ferrous metals |
| S | Special, super and titanium alloys |
| H | Hardened steel and chilled cast iron |
On the following programme pages you will find for every tool recommendations regarding suitability for the application groups and details of max. tensile strength and harness:
optimal suitability
limited suitability
optimal suitability
limited suitability
- Connection code machine side
- straight shank
- Internal cooling
- without
- Norm
- ~DIN 374
- Surface
- TiN
- Discount group
- 103
- Type
- 1258
- Cutting direction
- right-hand
- Type
- N
- Material
- HSS-E-PM
- Additional information
- Internal threading
- Form
- C
- Threads
- MF
- Tolerance class thread
- 6HX
- Hole type
- through-, blind hole
- Groove
- without oil grooves
- Chamfer lead length
- 2-3
- Code no.
- 14.007
- Weight
- 0.008
- Total length
- 100.000
- Thread length
- 20.000
- Usable length
- 40.000
- Norm 2
- DIN 2174
- Wrench opening 1
- 9.000
- Neck Ø
- 10.800
- Core hole Ø
- 13.30
- Shank Ø
- 11.000
- Nominal dimension thread
- M14 x 1,5
- Pitch
- 1.500
- External Ø
- 14.080
- Reach length
- 45.000
- Statistical goods number
- 82074010
Alert
Error when calculating the cutting values
Use case
Dimensions
mm
mm
mm
mm
%
mm
Material
All values given are approximate values. The actually accomplishable cutting-speeds and feed-rates depend on the particular processing conditions. We recommend according cutting tests
